Description
The Sennheiser EW-D SK is an extraordinarily versatile and feature-rich Digital UHF Bodypack Transmitter, for use with Evolution Wireless Digital Receivers. An ideal product for those who sing, speak or play instruments that provide seamless product pairing and management via the EW-D Smart Assist App.
This particular Bodypack Transmitter is compatible with various Sennheiser Headset/Lavalier Microphones, and operates within the frequency range of U1-5: 823.2 – 831.8 MHz & 863.2 – 864.8 MHz.
Product Features:
- Digital wireless eliminates noise, interference & static bursts
- Automated setup creates connections with minimal time/effort
- UHF transmission greatly enhances range, reliability and scalability
- Mobile App streamlines setup and operation and eliminates complicated menu
- Up to 2,240 selectable frequencies support up to 24 wireless systems per frequency range
Contents:
- x1 Pouch
- x1 Quick Guide
- x1 Safety Guide
- x1 EW-D SK Bodypack Transmitter
- x1 Manufacturer Declaration Sheet
Specifications:
EW-D SK | |
|---|---|
Frequency Response | 20 Hz – 20 kHz @ -3 dB |
Frequency Range | 823.2 – 831.8 MHz & 863.2 – 864.8 MHz (U1/5) |
Occupied Bandwidth | 200 kHz |
Input Current | < 300 mA |
Input Voltage | 2.0V – 4.35V |
Power Supply | x2 AA batteries 1.5V (Alkali Manganese), or BA 70 Rechargeable Battery Pack |
Transmission Power | Audio Link = 10 mWBLE = max. 10 mW EIRPERP = Range Y1-3: 12 mW ERP |
Operating Temperature | -10 °C – +55 °C |
Weight | 120g; excluding batteries |
Dimensions | 63 mm W x 80 mm H x 20 mm D; excluding antenna |
Accessories (Included) | N/A |
Accessories (Optional) | N/A |
To view additional information, be sure to check out the Data Sheets below.
